Diode Surgical Laser Machine VDL10
VDL10 Diode Laser Surgery Machine
- SKU
- VDL10
- Brand
- MoreVET
- Manufactured by
- MoreVET
- Availability
- In stock
- ✓ Worldwide shipping
Clinical overview
Product overview
Features
- Pain relief, wound healing
- Glaucoma
- Ectopic cilia / Trichiasis
- Gingivitis
- Dye-enhanced coagulation
- Cancer management
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
Laser Type |
Semiconductor laser |
|
Wavelength |
980 nm + 650 nm |
|
Output Power |
CW 15 W, ISP 20 W |
|
Operation Mode |
CW, Pulse |
|
Pulse Duration |
25μs-10s |
|
Repetition Rate |
0.2Hz-20KHz |
|
Transmission system |
Contact: fibers of 400μm or 600μm (randomly assigned) with SMA905 connector; Support 1000um; Non-contact: fibers, tips and hanpiece |
|
Aiming Beam |
Diode Laser of 650 nm, 4mW (max), adjustable brightness |
|
Cooling |
Air cooling and TEC |
|
Control Mode |
Color LCD touch Screen |
|
Laser Class |
4 |
|
Power supply |
100-240 V, 50-60 Hz, 400 VA |
|
Fuse |
F5AH250V |
|
Safety classification |
Class II Type B |
|
Dimension and weight |
135*223*130 mm, 1.8 kg |
|
Operating Temperature |
+10 ~ +35 ℃ |
|
Storage / Transport Temperature |
-20 ~ +55 ℃ |
|
Humidity |
Storage / Transport: 10% – 80%, Operating: 30% – 60% |
|
Waterproof level |
IPX1 |
|
Footswitch Waterproof level |
IPX8 |
Technical specifications
Engineering at a glance
Documentation, IFU and DOCs available on request — contact our sales team for the full regulatory file.
- Laser Type
- Semiconductor laser
- Wavelength
- 980 nm + 650 nm
- Output Power
- CW 15 W, ISP 20 W
- Operation Mode
- CW, Pulse
- Pulse Duration
- 25μs-10s
- Repetition Rate
- 0.2Hz-20KHz
- Transmission system
- Contact: fibers of 400μm or 600μm (randomly assigned) with SMA905 connector; Support 1000um; Non-contact: fibers, tips and hanpiece
- Aiming Beam
- Diode Laser of 650 nm, 4mW (max), adjustable brightness
- Cooling
- Air cooling and TEC
- Control Mode
- Color LCD touch Screen
- Laser Class
- 4
- Power supply
- 100-240 V, 50-60 Hz, 400 VA
- Fuse
- F5AH250V
- Safety classification
- Class II Type B
- Dimension and weight
- 135*223*130 mm, 1.8 kg
- Operating Temperature
- +10 ~ +35 ℃
- Storage / Transport Temperature
- -20 ~ +55 ℃
- Humidity
- Storage / Transport: 10% – 80%, Operating: 30% – 60%
- Waterproof level
- IPX1
- Footswitch Waterproof level
- IPX8
Documents & downloads
Regulatory paperwork & manuals
Pre-cleared documentation for this device. Full tender-pack originals are available on request.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
