Portable USB Video Gastroscope/ Colonoscope
VED-6000B Portable USB Video Gastroscope/ Colonoscope
- SKU
- VED-6000B
- Brand
- MoreVET
- Manufactured by
- MoreVET
- Availability
- In stock
- ✓ Worldwide shipping
Clinical overview
Built for surgical precision
Features
- The multifunctional Gastroscope using polycarbonate new composite handle, reasonable designed the clamp hole position, the washable pipe system can protect the lotion unobstructed, to prevent the pipeline blockage, with biopsy forceps hole to ensure the pliers and other devices unobstructed. When do surgery, the suction valve is convenient, removable, safe and reliable, so that users do not feel fatigue in the operation.
- The excellent operation of the traction device an be easily transfer and adjust the bending parts to upward, downward. Can smoothly and fastly reach to the desired site of observation. And timely and accurate detection of diseased tissue.
- The scope with multi-coated high transmittance imaging system, round field of view, wide viewing angle, wide field of view, the scene is broad and wide, 3-100 mm range can see more clear picture, so that the observation and diagnosis correctness greatly improved.
- The high-definition CMOS camera makes users to get clearer, wide and bright image.
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
View of field |
140° |
|
Diameter of distal-end |
Φ12.8mm |
|
Outer diameter of insert tube |
Φ12.8mm |
|
Depth of view |
3-100mm |
|
Working length |
3000mm |
|
Working channel |
Φ3.2mm |
|
LCD |
Use computer LCD |
|
Image solution |
CMOS 1,000,000 pixels |
|
Bending range |
Up 180°, Down 90°, L/R 100° |
Parts List
|
PRODUCT NAME |
UNIT |
QUANTITY |
|
Portable Gastroscope |
set |
1 |
|
Biopsy forceps |
set |
6 |
|
Cleaning brush |
set |
1 |
|
Leak detector |
set |
1 |
|
Attract valve anti jet cover |
set |
2 |
|
Endoscope case |
set |
1 |
|
Mini pump (Portable) |
set |
1 |
|
Charge |
set |
1 |
|
User manual |
pc |
1 |
|
Portable LED light source |
pc |
1 |
Optional
|
PRODUCT NAME |
PICTURE |
SPECIFICATIONS |
|
Laptop computer |
HUAWEI MateBook D 14 SE |
|
|
Light cold source machine |
1. Voltage: 220V-240V 2. Frequency: 50-60HZ 3.lamp Power: 15V-150W environmentally friendly halogen tungsten lamp 4. Illumination: 70000LX (using special measuring tools) 5. Color Temperature: 3000~7000K 6. Air Pump Pressure: 30-60kpa 7. Air Flow: 4L/min-10L/min (Quiet pump) |
|
|
Trolley |
|
Technical specifications
Engineering at a glance
Documentation, IFU and DOCs available on request — contact our sales team for the full regulatory file.
- View of field
- 140°
- Diameter of distal-end
- Φ12.8mm
- Outer diameter of insert tube
- Φ12.8mm
- Depth of view
- 3-100mm
- Working length
- 3000mm
- Working channel
- Φ3.2mm
- LCD
- Use computer LCD
- Image solution
- CMOS 1,000,000 pixels
- Bending range
- Up 180°, Down 90°, L/R 100°
- PRODUCT NAME
- UNIT QUANTITY
- Portable Gastroscope
- set 1
- Biopsy forceps
- set 6
- Cleaning brush
- set 1
- Leak detector
- set 1
- Attract valve anti jet cover
- set 2
- Endoscope case
- set 1
- Mini pump (Portable)
- set 1
- Charge
- set 1
- User manual
- pc 1
- Portable LED light source
- pc 1
- PRODUCT NAME
- PICTURE SPECIFICATIONS
- Laptop computer
- HUAWEI MateBook D 14 SE
- Light cold source machine
- 1. Voltage: 220V-240V 2. Frequency: 50-60HZ 3.lamp Power: 15V-150W environmentally friendly halogen tungsten lamp 4. Illumination: 70000LX (using special measuring tools) 5. Color Temperature: 3000~7000K 6. Air Pump Pressure: 30-60kpa 7. Air Flow: 4L/min-10L/min (Quiet pump)
Documents & downloads
Regulatory paperwork & manuals
Pre-cleared documentation for this device. Full tender-pack originals are available on request.
Documents & downloads
Regulatory paperwork & manuals
This device's IFU, CE Declaration of Conformity, ISO 13485 certificate and (where applicable) FDA 510(k) clearance ship with the order. Reach out below for the pack ahead of purchase.
Get in touch
Need configuration help, certificates, or volume pricing?
Our clinical sales team will scope quantities, voltage, accessories and regulatory paperwork — usually within one business day.
